TEBA 21 PCS Custom Non-standard Metric Keyway Broaches

Product parameters

Pieces

No. of Broaches | No. of shim | No. of Bushings | Keyway combinations | Model. No.

6

2 Broaches: 2mm, 3mm (A) | 1 | 3 Bushings: 6,8,10mm | 6 | 395-0806

16

2 Broaches 16mm,18mm (E-1) | 6 | 8 Bushings:52,54,55,56,58,60,62,65mm | 16 | 395-0816

18

4 Broaches 4mm, 5mm (B-1), 6mm, 8mm (C-1) | 5 | 9 Bushings: 12, 14, 16, 18, 20, 22, 24, 26, 28mm | 18 | 395-0818

21

3 Broaches 10mm,12mm,14mm (D-1) | 6 | 12 Bushings: 32,34,35,36,38,40,42, 44,45,46,48,50mm | 36 | 395-0821

22

4 Broaches 4mm,5mm (B-1),6mm,8mm (C-1) | 5 | 13 Bushings: 12,14,15,16,18,19,20,22, 24,25,26,28,30mm | 26 | 395-0822

Pieces

No. of Broaches | No. of shim | No. of Bushings | Keyway combinations | Model. No.

9

3 Broaches: 1/16-A,3/32-A,1/8-A | 1 | 5 Bushings: 1/4,5/16,3/8,7/16,1/2" | 15 | 395-0109

17

2 Broaches: 5/8, 3/4" | 9 | 6 Bushings: 2-5/16,2-7/16,2-9/16,2-11/16,2-13/16,2-15/16" | 12 | 395-0217

17

2 Broaches: 5/8-E, 3/4-E | 9 | 6 Bushings: 2-3/8,2-1/2,2-5/8,2-3/4,2-7/8,3" | 12 | 395-0218

22

4 Broaches: 5/16-D,3/8-D,7/16-D,1/2-D | 10 | 8 Bushings: 1-7/16,1-9/16,1-11/16,1-13/16,1-15/16,2-3/16,2-7/16,2-15/16 | 32 | 395-0322

22

4 Broaches: 5/16-D,3/8-D,7/16-D,1/2-D | 10 | 8 Bushings: 1-1/2,1-5/8,1-3/4,1-7/8,2, 2-1/8,2-1/4,2-1/2" | 32 | 395-0323

32

3 Broaches: 1/2-D, 5/8-E,3/4-E | 12 | 17 Bushings: 2, 2-1/16, 2-1/8, 2-3/16, 2-1/4, 2-5/16,2-3/8,2-7/16,2-1/2, 2-9/16, 2-5/8, 2-11/16,2-3/4, 2-13/16, 2-7/8, 2-15/16, 3 | 26 | 395-0432

75

8 Broaches: 1/8,3/16"(B),1/4,5/16"(C), 3/8,7/16,1/2"(D),5/8, (E) 3/4" | 22 | 44 Bushings: 1/2,9/16,5/8,11/16,3/4,13/16,7/8,15/16,1,1-1/16,1-1/8,1-3/16,1-1/4, | 102 | 395-0575

15

3 Broaches: 1/8-B, 3/16-C, 1/4-C | 3 | 9 Bushings: 1/2, 5/8, 3/4, 7/8, 1, 1-1/8, 1-1/4, 1-3/8, 1-1/2 | 15 | 395-0717

18

4 Broaches: 1/8-B,3/16-B,1/4-C3/8-C | 5 | 9 Bushings: 1/2, 5/8, 3/4, 7/8, 1, 1-1/8, 1-1/4, 1-3/8, 1-1/2 | 18 | 395-0718

18

4 Broaches: 1/8-B,3/16-B,1/4-C3/8-C | 5 | 9 Bushings: 9/16,11/16,13/16,15/16,1-1/16,1-3/16,1-5/16,1-7/16,1-9/16 | 18 | 395-0719

27

4 Broaches: 1/8-B,3/16-B,1/4-C3/8-C | 5 | 18 Bushings: 1/2,9/16,5/8,11/16,3/4,13/16,7/8,15/16,1,1-1/16,1-1/8,1-3/16, | 36 | 395-0727

30

5 Broaches: 1/8", 3/16"(B),1/4",5/16",3/8"(C) | 7 | 18 Bushings: 1/2,9/16,5/8,11/16,3/4,13/16,7/8,15/16,1,1-1/16,1-1/8,1-3/16,1-1/4,1-5/16,1-3/8, | 47 | 395-0730
